How To Make Co2 Gas Commercially Industrial Methods?

Carbon dioxide gas is made commercially on a massive scale using a few established industrial methods. The most common approaches are capturing CO2 as a byproduct from ammonia production, recovering it from natural gas processing, and separating it from flue gas at power plants and refineries. These methods produce millions of tons of CO2 each year for use in food and beverage carbonation, fire suppression, chemical manufacturing, and enhanced oil recovery.

What Is the Main Commercial Source of CO2?

Most commercial CO2 does not come from a dedicated production process. It is captured as a byproduct of other industrial operations. This is the key fact to understand about the industry.

Ammonia production is the single largest source of commercial CO2. Ammonia plants produce hydrogen by reacting natural gas with steam. This process, called steam methane reforming, also produces a concentrated stream of CO2. Because the CO2 is already separated from other gases in the process, it is relatively easy and cheap to capture, purify, and compress for sale.

Other major byproduct sources include ethanol fermentation plants, where yeast produces CO2 while converting sugar into alcohol, and hydrogen production facilities. These sources are valuable because the CO2 concentration in the gas stream is high, which makes purification simpler and less expensive than extracting CO2 from dilute sources like power plant exhaust.

How Is CO2 Captured From Ammonia Production?

The ammonia production process begins with natural gas, which is mostly methane. The methane reacts with steam under high temperature and pressure to form hydrogen and carbon monoxide. A second reaction, called the water-gas shift reaction, converts the carbon monoxide into CO2 and more hydrogen.

At this point, the gas mixture is roughly 18 percent CO2. The CO2 is removed using a chemical absorption process. A solvent, typically a solution of potassium carbonate or an amine compound, is sprayed into the gas stream. The solvent chemically binds with the CO2, pulling it out of the gas mixture.

The solvent is then heated in a separate vessel. Heat reverses the chemical bond, releasing nearly pure CO2 gas. The solvent is cooled and recycled back into the process. The released CO2 is compressed and dried, and impurities are removed. The final product is typically 99.9 percent pure CO2, suitable for food and beverage use.

How Is CO2 Recovered From Natural Gas Processing?

Raw natural gas pulled from underground reservoirs often contains significant amounts of CO2. Some gas fields produce gas that is 5 to 10 percent CO2, and some can be much higher. This CO2 must be removed before the gas can be sold, because CO2 reduces the energy content of the gas and can cause pipeline corrosion.

The CO2 removal step at natural gas processing plants uses the same type of chemical absorption technology used at ammonia plants. Amine solvents are the most common choice. The captured CO2 is then purified and compressed for commercial sale.

This source is particularly important in regions with large natural gas production. In the United States, natural gas processing accounts for a significant share of commercial CO2 supply, especially in states like Texas, Wyoming, and Kansas.

How Is CO2 Extracted From Flue Gas?

Flue gas is the exhaust produced when coal, natural gas, or oil is burned. It exits power plants and industrial boilers through smokestacks. Flue gas typically contains only 3 to 15 percent CO2, with the rest being mostly nitrogen and oxygen.

Extracting CO2 from flue gas is technically possible but more expensive than capturing it from high-concentration sources. The low CO2 concentration means much larger volumes of gas must be processed to recover the same amount of CO2. This requires bigger equipment and more energy.

The most common method for flue gas capture is amine-based chemical absorption, operating on the same principle as ammonia plant capture. The flue gas is first cooled and cleaned of particulates and sulfur compounds. It then passes through an absorber column where the amine solvent binds with CO2. The solvent is regenerated by heating, releasing concentrated CO2.

Flue gas capture is used commercially, but it is less common than byproduct capture because of the higher cost. It becomes economically attractive only when CO2 prices are high, such as for enhanced oil recovery operations.

What Is the Cryogenic Method for Producing CO2?

Cryogenic separation is a different approach that uses extreme cold to separate CO2 from other gases. It relies on the fact that CO2 becomes a liquid or solid at much higher temperatures than nitrogen or oxygen.

In this process, a gas stream containing CO2 is compressed and cooled in stages. As the temperature drops, CO2 condenses into a liquid while the other gases remain in vapor form. The liquid CO2 is then separated and further purified.

Cryogenic separation works best with gas streams that already have high CO2 concentrations, typically above 50 percent. Natural gas processing is a common application, because some gas reservoirs produce streams that are predominantly CO2. The method is efficient for these high-concentration sources but impractical for dilute streams like flue gas.

A specialized form of cryogenic processing is used at natural CO2 wells. Some geological formations contain nearly pure CO2 gas. These wells are drilled, and the gas is brought to the surface, purified, and compressed. This is the simplest commercial method of all, but it depends on the rare geological conditions where natural CO2 reservoirs exist.

What Are the Steps After CO2 Is Captured?

Raw CO2 from any source requires purification before it can be sold. The specific steps depend on the intended use, but the general sequence is consistent.

First, the CO2 is dried. Water must be removed because it combines with CO2 to form carbonic acid, which corrodes pipelines and equipment. Drying is typically done using desiccant materials like molecular sieves.

Next, impurities are removed. The most common impurities are sulfur compounds, which cause odors and corrosion, and trace hydrocarbons. For food-grade CO2, additional purification removes compounds that could affect taste or safety.

Finally, the purified CO2 is compressed to high pressure. It is typically compressed to about 300 pounds per square inch for pipeline transport as a dense fluid. For storage in cylinders, it is compressed to around 800 to 1,000 pounds per square inch, where it exists as a liquid at room temperature.

How Is CO2 Stored and Transported?

CO2 is transported in three main forms: as a liquid in cylinders and tankers, as a dense fluid in pipelines, and as a solid in the form of dry ice.

Liquid CO2 transport is the most common for commercial distribution. The CO2 is kept under pressure in insulated tanker trucks and rail cars. At the delivery site, it is transferred to pressurized storage tanks at the customer’s facility.

Pipeline transport is used for very large volumes, particularly in enhanced oil recovery operations. These pipelines carry CO2 as a supercritical fluid, meaning it has properties of both a liquid and a gas. The CO2 is maintained at high pressure and moves through dedicated pipelines spanning hundreds of miles.

Dry ice is produced by expanding liquid CO2 through a nozzle into a chamber. The rapid pressure drop causes the CO2 to cool dramatically and form solid snow, which is then compressed into blocks or pellets.

Which Industrial Method Is Most Common?

Byproduct capture from ammonia production is the most common method worldwide. This is because ammonia plants produce a steady, high-concentration CO2 stream that is inexpensive to purify.

Natural gas processing is the second most common source. It is particularly dominant in the United States, where large natural gas reserves contain substantial CO2.

Flue gas capture, despite receiving the most attention in climate discussions, is the least common commercial method. It remains economically challenging and is used mainly where CO2 demand and prices justify the higher capture cost.

Natural CO2 wells are geographically limited but provide the lowest-cost CO2 in the regions where they exist. The Bravo Dome field in New Mexico and the Jackson Dome field in Mississippi are two notable examples in the United States.

What Are the Safety Considerations for Industrial CO2 Production?

CO2 is not toxic, but it can be dangerous in enclosed spaces. It is heavier than air and can accumulate in low-lying areas, displacing oxygen. At concentrations above about 10 percent, CO2 can cause rapid unconsciousness and death.

Industrial CO2 facilities are designed with continuous gas monitoring systems. Ventilation systems prevent CO2 buildup in work areas. Personnel working in confined spaces use personal monitors and follow strict entry procedures.

High-pressure CO2 systems also pose physical hazards. A ruptured line or vessel can release gas explosively. Liquid CO2 can cause severe frostbite on contact because it is stored at extremely low temperatures.

Regulatory oversight of CO2 production facilities falls under agencies like the Occupational Safety and Health Administration in the United States. Facilities must follow process safety management regulations and maintain emergency response plans.
