How Do Caissons Work Types Methods And Risks?

Caissons are watertight chambers that let workers dig below water or below the water table without being flooded. They work by holding back water and, in many cases, by using compressed air to keep water out while people work inside. There are three main types: open caissons, pneumatic caissons, and floating caissons. Each has a distinct method and a distinct set of health and safety risks, and the risks to workers are the part most people never hear about.

How Do Caissons Work Types Methods And Risks?

A caisson is essentially a box that becomes part of the structure it helps build. It is sunk into the ground or water, and the space inside is kept dry enough for workers to excavate and pour concrete.

The word comes from the French for “large box.” That is a good way to picture it. A hollow chamber is lowered into place. Workers remove material from inside, and the caisson settles lower as they dig. Once it reaches the required depth, the chamber is filled with concrete and becomes a permanent foundation element.

The central problem caissons solve is simple. You cannot dig a normal foundation in a riverbed, a harbor, or saturated ground without water rushing in. A caisson gives workers a controlled dry space to do the same job.

Open Caissons

An open caisson is open at both the top and the bottom. It sinks under its own weight as workers or machines remove soil from inside. Water is usually pumped out, or the work happens in the dry if the ground allows it.

These are the simplest and cheapest type. They work well in soft ground and shallow water. They are not suitable where water inflow is too strong to control with pumps, or where the ground is too hard to excavate from inside.

Pneumatic Caissons

A pneumatic caisson is sealed at the top and uses compressed air to hold water out of the working chamber. The increased air pressure inside the chamber pushes back against the water pressure outside. This allows workers to excavate in the dry, even below the water table or under a river.

This is the method that creates the serious medical risk. Working in compressed air means the body absorbs extra gas, and returning to normal pressure too quickly can cause decompression sickness. This is the same fundamental problem faced by divers.

Floating Caissons

A floating caisson is built on land, floated into position, then sunk. It is typically used for bridge piers and marine structures. Once in place, it is filled with concrete or ballast to make it stable and permanent.

This method avoids sending workers into compressed air for the sinking phase, which removes the decompression risk from that stage. It still involves heavy marine construction hazards.

What Is Caisson Disease?

Caisson disease is decompression sickness. It got its name because it was first widely recognized in workers building bridge foundations using compressed air caissons in the nineteenth century.

When a person breathes air at higher-than-normal pressure, extra nitrogen dissolves into the blood and tissues. If the pressure drops too fast, that nitrogen comes out of solution and forms bubbles in the body. Those bubbles can block blood flow and damage tissue.

Symptoms can include joint pain, skin rashes, dizziness, headache, shortness of breath, and in severe cases neurological problems or collapse. The classic joint pain is why the condition is sometimes called “the bends.”

The key point for workers is that this is a pressure-change problem, not a depth problem. It happens because of how fast pressure is reduced, not simply because the pressure was high.

How Is Decompression Risk Managed?

Decompression risk in caisson work is managed by controlling how fast workers return to normal pressure. This is done with staged decompression, where workers spend time at intermediate pressures before fully exiting.

Regulatory frameworks in many countries set limits on pressure, exposure time, and decompression schedules for compressed-air work. In the United States, OSHA has standards for compressed air work that address pressure limits, decompression procedures, and medical requirements.

Some general principles apply across these frameworks:

• Workers should not return to normal pressure too quickly.
• Exposure time at high pressure is limited.
• Medical screening helps identify people at higher risk.
• Workers showing symptoms need prompt evaluation and treatment.

Treatment for significant decompression sickness typically involves recompression in a hyperbaric chamber, where pressure is increased again and then slowly reduced. This is a medical emergency, not something to wait out.

No clinical guidelines currently exist for caisson work in pregnant women, and compressed-air work is generally avoided during pregnancy. That is a precaution based on limited data, not a firmly established threshold.

What Other Risks Do Caisson Workers Face?

Decompression sickness gets the most attention, but it is not the only hazard. Caisson work is heavy construction in a confined, often wet, and sometimes unstable environment.

Common risks include:

• Caisson sinking or collapse, which can trap or crush workers.
• Flooding if water control fails, especially in open caissons.
• Oxygen deficiency or contaminated air in enclosed chambers.
• Falls and falling objects in deep shafts.
• Noise and vibration from excavation equipment.
• Heat stress in compressed-air chambers, where air tends to warm as it compresses.
• Musculoskeletal strain from manual excavation and material handling.

Some of these are managed with engineering controls, some with personal protective equipment, and some with procedural rules. The compressed-air environment adds a layer of complexity because it affects both the physiology of workers and the behavior of equipment.

Why Are Caissons Still Used?

Caissons remain a standard method for foundations that must reach below water or below weak surface soils. They are used for bridge piers, harbor structures, and some large building foundations near water.

Alternatives exist. Pile foundations, for example, can transfer loads to deeper soil without sending workers down. Diaphragm walls and other retaining systems can also create dry working conditions. The choice depends on depth, ground conditions, water pressure, cost, and access.

Caissons are not obsolete, but they are not the default choice either. In many modern projects, other methods are preferred because they reduce the need for workers to enter compressed air or deep excavations. That is a safety-driven shift as much as a technical one.

One non-obvious point: the medical risk of caisson work is not mainly about the depth of the water or the depth of the hole. It is about the pressure inside the working chamber and how that pressure is managed. Two caissons at the same depth can carry very different risks depending on whether compressed air is used and how decompression is handled.

What Should Workers and Employers Know?

For workers, the most important thing is to report symptoms. Joint pain, dizziness, or unusual fatigue after a compressed-air shift is not something to ignore. Early treatment matters.

For employers, the priorities are pressure control, decompression scheduling, air quality monitoring, and medical oversight. These are not optional extras. They are the core of safe compressed-air work.

There is no single number that makes caisson work safe. Pressure, time, temperature, individual health, and decompression procedure all interact. That is why the standards focus on procedures and monitoring rather than a single limit.
